7Getting to know your smart display
Back view
Back panel
No. Item Description
7 USB ports (Master) Connects USB devices to your smart display, such
as a keyboard, mouse or storage device.
8 Port cover Open this cover to find the power, network and
HDMI ports, and the microSD card slot.
9 Stand Pull the stand open to provide a stable base for
your smart display.
10 3.5 mm headphone jack Connects to stereo headphones.
11 Micro USB port (Slave) Connects to a computer via a USB cable.
Allows access to the smart display’s storage from
the computer.
No. Item Description
12 Ethernet (RJ-45) port Connects to an Ethernet network.
13 DC-in jack Connects to the DC power supply.
14 MicroSD card slot Accepts a microSD card.
Note: To remove the card, press it into the slot,
then release and pull it from the slot.
15 Micro HDMI port Supports high-definition digital video connections.
