Acer X1160' Service Manual

X1160 Family/X1260 Family
Condential
3-6
Power on (as soon as power button
pressed)
So(0.3s)
Power on (lamp lighting failed) 2 x {So(0.1s) – Off(0.1s)} per lighting failure
12s interval for each trial lighting. Max 4 times
of trial
Power on (lens cap was not opened, for
the model with sliding lens cover only)
2 x {So(0.1s) – Off(0.1s)} periodically per 3
seconds, Totally 5 cycles. Turn off projector
after 5 cycles.
Close lens cap while projector is operat-
ing (for the model with sliding lens cover
only)
2 x {So(0.1s) – Off(0.1s)} periodically per 3
seconds, Totally 5 cycles. Turn off projector
after 5 cycles.
Power off (power button pressed twice) So(0.3s)
Fan lock So(0.1s) periodically per second
Overheat 2 x {So(0.1s) – Off(0.1s)} periodically per sec-
ond
Lamp error 3 x {So(0.1s) – Off(0.1s)} periodically per sec-
ond
Lamp Life reminding 3 x {Do(0.2s) – Off(0.8s) – So(0.2s) –
Off(0.8s)} with reminding message
Presentation Timer (time is up) 3 x {Do(0.1s) – Off(0.9s)} - So(0.5s)
3-3 Beep Sound

Acer X1160' Specifications

General

Number of colors	16.78 million colors
Projection distance	11.9 m
Vertical scan range	50 - 85 Hz
Horizontal scan range	31 - 69 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	0.64 - 7.62 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	±40 °
Digital zoom	2 x
Aspect ratio	4:3, 16:9
Power supply	255 W
Dimensions (WxDxH)	267 x 187 x 80 mm
Lamp type	P-VIP
Lamp power	160 W
Light source type	Lamp
Service life of light source	4000 h
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Noise level	33 dB
Power consumption (standby)	8 W

Weight and Dimensions

Weight	2300 g
