Acer X193HQ Service Guide

7
Monitor Features
Introduction
Scope
This specification defines the requirements for the 18.5” MICROPROCESSOR based Multi-mode supported high
resolution color LCD monitor. This monitor can be directly connected to general 15-pin D-sub VGA connector, also
supports VESA DPMS power management and plug & play function.
Description
The LCD monitor is designed with the latest LCD technology to provide a performance oriented product with no
radiation. This will alleviate the growing health concerns. It is also a space saving design, allowing more desktop
space, and comparing to the traditional CRT monitor, it consumes less power and gets less weight in addition MTBF
target is 50k hours or more.
Chart of X193HQ
Panel M185XW01 V00 SZ AUO
Signal Interface D-Sub 15pin
Sync Type Separate / Compatible
Color Temp User Adjust Support
DDC DDC2B
Speaker Yes
Headphone Jack Yes
Microphone Jack No
USB Hub Not support
Tilt / Swivel Yes / No
Chapter 1
http://www.wjel.net

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
