Acer X193HQ Service Guide

9
LCD Monitor General Specification
Driving system TFT Color LCD
Active Display Area 409.8 (H) × 230.4(V)
Pixel pitch 0.3(H) x 0.3(W)
Contrast Ratio 1000 : 1
Response time 5ms
LCD Panel
Luminance of White
300(Typ.) cd/㎡
Separate Sync. H/V TTL
H-Frequency 30kHz – 60kHz
Input
V-Frequency 40-75Hz
Viewing angle (H)170 (V) 160(Type)
Display Colors 16.7M
Display mode 1366 x 768 @60Hz
ON Mode < 37W
EPA ENERGY STAR®
OFF Mode < 1W
Contrast control
Set to The value under user mode, which allows that the brightest two of 32 linear
distributed gray-scales (0～ 700mv) can be distinguished.
Power Source
90 V ~ 240 V，50 ± 3Hz, 60 ± 3Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -30° to 65°C
Operating Humidity: 0% to 90%
Storage Humidity: 0% to 90%
Peak surge current < 55A peak at 240 VAC and cold starting
Power line surge
No advance effects (no loss of information or defect) with a maximum of 1 half-wave
missing per second
http://www.wjel.net

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
