ACLAS TS5X - Linerless Paper Installation

8
2.2.3. Linerless Paper Installation
Note:
For avoiding printing deviation caused by photoelectric detection mistake please avoid photoelectric
black mark on linerless paper (picture below) when customize your linerless paper with logo.
Picture:
Keep this slider aside, and
keep the paper on the slider
Insert paper roll
downwards
Pull out the paper
Move up and down to fix the paper
Push the handle and
fix the paper roll
Photoelectric
black signal
Logo should be away
from this place
