ACO 6226 - Page 34

33
4．Detail of Command
CMD Function Item
Type of
data
Outline of Functions
Time and date
setting request
ASCII(13) YYMMDDHHMMSS
ｔ
Time and date
setting completed
Without data part
Ｆ
Transfer
Configuration file
ASCII(6)
Ａ Ｂ Ｃ Ｄ Ｅ Ｆ
Ａ
：Meas Time Setting（１）
０；＊＊＊ １；１ｓ
２；３ｓ ３；５ｓ
４；１０ｓ ５；１ｍ
６；５ｍ ７；１０ｍ
８；１５ｍ ９；３０ｍ
Ａ；１ｈ B；８ｈ C；２４
ｈ
Ｂ
：Range Setting（１）
０；１３０ｄＢ １；１２０ｄＢ
２；１１０ｄＢ 3；１００ｄＢ
４；９０ｄＢ 5；８０ｄＢ
Ｃ
：Filter Setting（１）
０；Ａ １；Ｃ 2；F
Ｄ
：Time constant
０；Fast １；Slow 2；Imp
Ｅ
：Interval
０：Single １：Repeat
ｆ
Transfer
Configuration file
Without data part
Ｓ
Start measurement ASCII(1) Without data part
ｓ
Start measurement 〃
Ｅ
Stop measurement ASCII(1) Without data part
ｅ
Stop measurement 〃
ｒ
Data acquisition Without data part
Ｄ
Data request ASCII(1) Without data part
Data transfer Reference to 6-4
Ｃ
Data request ASCII(1) Without data part
Data transfer ASCII(1)
Ｌ
Data request ASCII(2) ０：lights out １：Lights up
Data transfer ASCII(1)
Ｒ
Independent
range setting
ASCII(2) ０：130 １：120 ２：110 ３：100 ４：90 ５：
80
ｒ
Answer ASCII(1) Without data part
Ａ
Filter setting ASCII(2) ０：A １：C ２：F
ａ
Answer ASCII(1) Without data part
Ｐ
Lp-value
acquisition
ASCII(1) Without data part
Data transfer ASCII(5) Reference to 6-5
