ACO 6226 - Section 1 Setting up; Locations and Their Functions

6
Section 1 Setting up
1. Locations and their functions
Microphone
Preamplifier
Threaded retaining ring
Front panel
Female screw
for tripod
Battery cover
Display
Side panel
Female screw for tripod
Side panel
Calibration potentiometer
AC OUT connector
DC OUT connector
POWER switch
AC power adaptor connector
External Input/Output connector
