2.5. Installation of External Fan (option)
This fan (see Figure 2-2 External fan) is not necessary in SSB and CW modes, nor in continuous carrier modes
(RTTY, SSTV, etc.) with carrier down times of maximum 15 minutes and a subsequent pause of 3 minutes.
For higher duty cycles such as continuous broadcast or increased ambient temperatures the fan is
recommended. The auxiliary fan (92x92 mm) must be brushless type, 2...5 W, 24 VDC. It may be installed
by your dealer or by the manufacturer on request.
Figure 2-2 External fan
Figure 2-2 External fan
