7. SPECIFICATIONS
7.1. Parameters
a) Frequency Coverage
All amateur bands in the 1.8-54 MHz frequency range;
Extensions and/or changes on request;
b) Power Output
1000 W PEP or continuous carrier, no mode limit;
NOTICE
In continuous carrier modes (RTTY etc.) for transmissions longer than 15 minutes (up to
several hours depending on ambient temperature), the external auxiliary fan must be
mounted.
c) Intermodulation Distortion
Better than 35 dB below rated output;
d) Hum and Noise
Better than 40 dB below rated output;
e) Harmonic Output Suppression
1.8-29.7 MHz - better than 50 dB below rated output;
50-54 MHz - better than 66 dB below rated output;
f) Input and Output Impedances
Nominal value: 50 Ohm unbalanced, UHF (SO-239A) type connectors;
Input circuit: broadband, SWR less than 1.3:1, 1.8-54 MHz continuously (no tunings, no
switching);
Bypass path SWR less than 1.1:1, 1.8-54 MHz continuously;
Output (antenna) impedance matching capability: SWR up to 3:1 or higher;
g) RF Gain
12.5 dB typically, frequency response less than 1 dB (50-60 W drive power for rated
output);
h) Mains Power Supply Voltage
85-132 VAC / 170-264 VAC (100, 110, 120, 200, 210, 220, 230 & 240 V nominal taps,
+10% -15% tolerance), 50-60 Hz, Single phase;
