Acom 1010 User Manual

User's Manual | ACOM 1010 | HF Linear Amplifier
Page
14
of
40
| S e c t i o n INSTALLATION
July 2021
2.3. Amplifier Location Selection
CAUTION
The weight of the unit is about 17 kg, which should preferably be handled by two
persons.
Position the amplifier near the place where it will be used. You will need an easy access to the command
knobs and indicator's area, as well as to the rear panel cabling.
No magnetic-field sensitive devices (such as microphones) should be located next to the right side of the
amplifier because its power transformer is located there. It is advisable to position the amplifier to the right
of your transceiver.
No temperature-sensitive devices should be located above the exhaust hot air area. This means that the
amplifier should not be located under a shelf or other structure that could impede the free movement of
air away from the amplifier.
NOTICE
Do not under any circumstances obstruct the air intake (bottom) and exhaust (top
cover) areas of the amplifier. Keep a minimum clearance distance of 50 cm (20 inches)
above the exhaust opening.
NOTICE
Do not leave accidental paper, cloth or other lightweight pieces around and under the
amplifier. They may be drawn in by the cooling air stream and block the vents. This will
lead to overheating and accelerated material aging, not covered by the warranty.

Acom 1010 Specifications

General

Complies with CE safety and electromagnetic compatibility requirements, as well as FCC regulations	Yes
Power Output	1000 W PEP
Modes	SSB, CW, RTTY, AM, FM
Power Supply	200-240VAC or 100-120VAC, 50-60Hz, single phase.
Cooling	Forced air
Harmonic Output	-50 dB
Input Impedance	50 Ohms
Output Impedance	50 Ohms
Tube	4CX800A
