Page #15 background imageLoading...
Page #15 background image
User's Manual | ACOM 1010 | HF Linear Amplifier
July 2021
S e c t i o n INSTALLATION | Page
15
of
40
2.4. Connections
Please, see Figure 2-1 Rear panel - Connections.
Connection to your station must be accomplished in the order described below, before you apply mains
voltage to the amplifier.
Before you connect the amplifier to external grounding, you should advise with a
licensed electrician and confirm such kind of connection is allowed by your national and
local electrical code, safety rules, and regulations in force. Simultaneous connection to
the earth grounding and protective earth may be inadmissible or may fall under special
requirements in some countries!
DANGER
Never use the gas installation for grounding. This can cause an EXPLOSION!
DANGER
Do not use the steam-heating or water-supply network for grounding! You may expose
to dangerous voltage not only yourself but also other people using the same installation.
a) GND stud
First, connect the wing-nut grounding stud of the amplifier (on the rear panel, marked GND) to the station's
grounding system (see Figure 2-1 Rear panel - Connections, Pos. (a)).
WARNING
Note that the grounding system may have to withstand currents over 15 A with
insignificant voltage drop on it. Therefore, it may be necessary to improve it
considerably, i.e., to become less resistive, with heavier leads and lower-resistive ground
path. The grounding leads should be at least 4 mm² (AWG 11 or SWG 13).

Other manuals for Acom 1010

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Acom 1010 and is the answer not in the manual?

Acom 1010 Specifications

General IconGeneral
Complies with CE safety and electromagnetic compatibility requirements, as well as FCC regulationsYes
Power Output1000 W PEP
ModesSSB, CW, RTTY, AM, FM
Power Supply200-240VAC or 100-120VAC, 50-60Hz, single phase.
CoolingForced air
Harmonic Output-50 dB
Input Impedance50 Ohms
Output Impedance50 Ohms
Tube4CX800A
