Setting Output Intensity
Output intensity can only be set when the selected channel tab(s) are
illuminated orange. Screen text saying “Ready to set the output”
appears during initial setup. As soon as intensity is increased the
START and STOP buttons appear.
Note:
 If a 2-channel application is selected to simultaneously
increase the intensity of both channels, press and hold both
channel tabs with your fingers until both channel tabs
illuminate orange.
 Within 12 seconds after setting the desired output intensity
the orange illuminated channel tab(s) fades to blue.
 If additional output adjustment is needed prior to selecting
START , press the channel tab with your finger and
it will illuminate orange.
Setting Output Intensity Simultaneously: 2 Channel Program
If a 2-channel application is selected to simultaneously increase the
intensity of both channels, press and hold both channel tabs with your
fingers until both channel tabs illuminate orange.
Pausing a Treatment
As soon as the Start button is pressed the PAUSE and STOP
buttons appear. To pause a treatment, touch the PAUSE
button.
 When PAUSE is selected output intensity ramps
down to 0 and the START and STOP
buttons reappear.
 A two bar orange pause Icon will appear at the top of
in the channel tab
 To resume the paused treatment, press the START
button, touch the channel tab(s) to illuminate orange and reset
the output intensity.
 After pressing PAUSE do not remove electrodes for
3 seconds to allow any remaining capacitance to dissipate.
Note:
 To end the treatment, touch the STOP button
 The treatment can also be stopped by pressing the emergency
stop icon
. Pressing this button stops the output on all
channels in use.
