Acrosser Technology AR-V6002FL - Page 26

Revision: 1.23
26
CN6: Bluetooth connector CN18: CANBUS connector
CN23: RI SELECT for
COM1/2
CN24: RI SELECT for
COM3/4
CN8: GPS connector GPIO1: GPIO connector
JP8,JP11: RS-232 / RS-422
/ RS-485 Selection for
COM1/2
SATA power connector1
CN5: RJ45 + USB X 2
connector
CN25 (Reserve): RI
SELECT for COM5/6
SATA power connector 2 CN7: USB connector
COM5 (Reserve): RS232
signal connector
CN2: CMOS clear
CN28: PIC Programming
connector.
JP5,JP6 (Reserve):
RS-485 Termination 120
ohm
CN13: SIM card slot
CN20: Setting
Voltage level of Battery
JP7,JP10: RS-232 / RS-422
/ RS-485 Selection for
COM1/2
BH1: CMOS battery VGA1:VGA connector
JP9,JP12: RS-232 / RS-422
/ RS-485 Selection for
COM1/2
Mini PCIe slot 1
SW1: DIP switch for
power mode select
U8: SPI BIOS Socket
CN9 Internal USB
COM1&COM2:
RS-232/422/485
CN21: BIOS
Programmable HEADER
CN10 Internal USB COM3&COM4: RS-232
DIMM1: DDR-3 SODIMM
Socket
Mini PCIe slot 2
AUDIO1: AUDIO
connector
SATA1: SATA device
connector #1
CN17: FPGA programming
header
PWR1: Power Input
Terminal Block Connector
SATA2: SATA device
connector #2.
LED1: Status LED
FUSE1: Fuse connector
