Revision: 1.23
44
3.4 PnP/PCI Setup
The option configures the PCI bus system. All PCI bus system on the system use INT#,
thus
all installed PCI cards must be set to this value.
Note: The control keys are listed at the bottom of the menu. If you need any help with the item fields,
you can press the <F1> key, and the relevant information will be displayed.
Item Option Description
Reset Configuration
Data
Enabled
Disabled
Normally, you leave this field Disabled.
Select Enabled to reset Extended System
Configuration Data (ESCD) when you
exit Setup. If you have installed a new
add-on and the system reconfiguration has
caused such a serious conflict, then the
operating system cannot boot.
Resources
Controlled By
Auto(ESCD)
Manual
The Award Plug and Play BIOS has the
capacity to automatically configure all of the
boot and Plug and Play compatible devices.
However, this capability means absolutely
