This chapter describes the installation of AR-B6050. At first, it shows the Function
diagram and the layout of AR-B6050. It then describes the unpacking information which
you should read carefully, as well as the jumper/switch settings for the AR-B6050
configuration
2.1 Locations of Connector and Jumper Setting
2.1.1 Locations (Top side)
