2.4 Remote Switch
We provide a remote switch cable with latch switch. Use the remote switch cable can let
user turn on and turn off system easier.
2.5 Status LED
The LED will flash a number of blink to state the status.
Mode 0 and 1:
LED will be constant ON when power output is ON. LED will be constant OFF when power
output is off.
Mode 2 to 7 and mode 15(Smart ATX mode):
Each blink remains 500 milliseconds ON followed by a 500 ms OFF. Each Cycle will have a
5-second OFF in between.
flashing number Status
0 (constant ON) Power Output runs normally
1 Hard off mode
2 Standby mode (After power output is turned off
until 5VSB is turned off)
3 Power soft off delay. (After ignition is turned off or
remote switch is pressed until power output is
turned off.)
4 Battery voltage low
5 System on/off fail. When motherboard cannot
turn on or turn off after retry.
6 Mode 8 / 9 / 10 / 11 / 12 / 13 / 14, which means
no function in current version.
6-128 Reserved
2.6 Fuse selection
AR-V6002FL has external fuse holder, user can swap fuse according to the application. We
provide 7.5A fuse for 12V car battery, so that user’s cable should be able to endure 7.5A at
least.
