Revision: 1.23
35
4
30 minutes 2 hours Ignition Ignition / Remote Switch
5
5 seconds 1 minute Remote Switch (2.4)
(Ignition must be on first)
Ignition / Remote Switch
6
1 minute 5 minutes Remote Switch
(Ignition must be on first)
Ignition / Remote Switch
7
30 minutes 2 hours Remote Switch
(Ignition must be on first)
Ignition / Remote Switch
15(Software
control)
By user setting By user setting By user setting Ignition / Remote Switch
Low power protection:
Power input monitoring(before system boot on, during runtime, during soft off delay): The
Power smart function will constantly monitor the input voltage. If the input voltage is below
X Voltage (the standard might have 5% tolerance), the Smart Mode will not start the
power on procedure. When Power smart function has ran in operation and the battery
drops below Y Voltage (with 5% tolerance) more than 10 seconds the Power smart
function will shut down the motherboard following the standard shut down procedure. If the
input voltage recovers in 10 seconds over Y Voltage (with 5% tolerance) again, the Power
smart function will continue to run. (Figure 4)if this happens, ignition shall be off and on
again (Mode 2, 3, 4) or press the remote switch(Mode 5,6,7) if you want to turn on system
again.
Important: Please make sure the CN20 jumper is set to the right setting
which meet your vehicle power system. The power subsystem uses this
setting to identify the voltage of your vehicle power system.
For 12V car battery For 24V car battery
X value
(Minimum Start up
voltage)
11.2 23
Y value
(Auto shut down voltage)
10.8 22.5
STATUS SETTING
1-2
+24V system
2-3
+12V system (Default).
