Acrosser Technology AR-V6002FL - Optional Module Specifications; Gps; Bluetooth

Revision: 1.23
83
5
OPTIONAL MODULE
SPECIFICATIONS
5.1 GPS
WIESON ZYM-5020 GPS Module
G5020-1 is a high performance, low power consumption、small size、very easy integrated
GPS engine board, designed for a broad spectrum of OEM system applications. The GPS
engine board will track up to 16 satellites at a time, provide fast time-to-first-fix and
one-second navigation updates.
Features
(1) Build on high performance Ublox5 chipset, -160dBm tracking sensitivity.
(2) Average Cold Start time and under 30 seconds. 16 channels “All-in-View” tracking,
providing accurate satellite position data.
(3) ±0.5ppm temperature compens ated crystal oscillators (TCXO) to offer higher stability.
Please refer to GPS user’s manual for details.
5.2 Bluetooth
Qcom QBTM400-01 Bluetooth Module
Features
- CSR BlueCore4-ROM (A07) Single Chip Bluetooth System
- Bluetooth 2.1 + EDR support
- Class 2 Bluetooth operation with full 7 slave Piconet support
- Full Speed USB interface compliant with USB V1.1 and compatible with
USB V2.0
- Single onboard Antenna connector support
- Simple Pairing, Version 2.1 + EDR to advance its short range wireless
technology and make it easier for consumers to connect Bluetooth devices.
Specification Compliance
- Bluetooth Specification V1.2, V2.0, V2.1 and V.2.1+EDR compliant
- USB Specification V1.1
- compatible with USB V2.0 Full Speed (12Mbits/s)
