A = X-ray emission switch
B = X-ray emission LED
• Keep the switch pressed for the whole duration of the exam until the U-arm stops. If the switch is released earlier, the
X-ray emission and the carriage movements will be stopped and the exam is irremediably interrupted (“dead man” exposure
mode); in this case, the device must be reset and the patient positioning redone.
CAUTION :
Monitor the patient throughout the entire exposure. In the event of an emergency, release the Xray exposure switch to stop the U-arm
rotation and X-ray emission.
In the event that the U-arm rotation and/or X-ray emission do not stop, press the remote emergency switch.
