Manufacturer Hamamatsu Photonics K.K.
Model FPD C12280D-40
Image voxel size 75 µm (minimum slice thickness)
Active area 121.6 x 123.1 mm
FOV (diameter x height)
40 mm x 60 mm
60 mm x 60 mm
80 mm x 80 mm
110 mm x 80 mm
NOTE :
A specic version of AIS software disables FOV 110mm X 80mm
Frame rate 35 frames/s
Sensitivity 6000 LSB/mR
Resolution 2.5 lp/mm
Dynamic range 3600
11.8 SCANNING PARAMETERS – PAN/CEPH
X-ray exposure time
PAN: 3.3 s – 13.5 s
CEPH:18 s
Scanning time
PAN: 16.8 s – 22.5 s
CEPH: 23 s
Tube voltage 60 – 85 kVp
Anodic current 4 – 10 mA
11.9 SCANNING PARAMETERS – CBCT
X-ray exposure time 4 s – 12 s
Scanning time 12 s – 30 s
Rotation 360°
X-ray real exposure time
6s (Normal quality)
7.2s (Medium quality)
9s (High quality)
Tube voltage 80 - 90 kVp
Anodic current 4 – 12 mA
11.10 LASER
Wavelength 650 nm
Operation voltage 2.7 to 5 V
Classication Class 1M
Diffractive optics Line, 90°
Collimating lens Aspheric plastic lens
Power 1 mW
