Operator’s manual • X-Mind trium • V0G • (13) • 10/2017 • NTR0EN040G
ENGLISH
10.2 TRIUM ERRORS
CODE Ser Message / Description Act Solution
0 C
"CHECK INTERNAL ETHERNET
Hw errror: mainboard and ETH switch
do not communicate
In this condition trium and
workstation cannot communicate;
THIS ERROR APPEARS ONLY ON THE
Trium DISPLAY"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
+ check connection cable between mainboard and ETHERNET
switch
+ ETHERNET switch
+ 12VDC power supply cable to ETHERNET switch
"
13 C Image detector not grabbing U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
+ check connection cable between image detector and
ETHERNET switch
+ check image detector"
66 E
"CONFIG_INFO_UPDATED
Conguration data have been
updated"
U/T
Restart trium and workstation in order modications are
effective
67 D
"MOTOR_AXES_DO_BREAK
WARNING: operator has intentionally
stopped a movement releasing XRay
button"
U
Wait the full exam procedure is completed before releasing
XRay button: message on workstation “exposure button can be
released”
68 B
"MOTOR_AXES_CNTL_FSM
Unexpected motors FSM condition"
A
Reset error from workstation; if error remains restart trium and
workstation.
69 C
"MOTOR_AXES_TRJ_LOAD
Trajectory loading from PC is failed"
A
Reset error from workstation; if error remains restart trium and
workstation.
70 C
"XRAYS_DISA_ETH_LINK
Xrays disabled due to ETH connection
failure"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check all ethernet connections between trium image detectors
and workstation;
check trium ethernet switch;
check that workstation conguration is in accordance with
requirements (network interface card, installed anti-virus,
rewall disabled…)"
71 C
"XRAYS_DISA_PC_ALARM
Xrays disabled due an alarm issued
from PC"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check all ethernet connections between trium image detectors
and workstation;
check trium ethernet switch;
check that workstation conguration is in accordance with
requirements (network interface card, installed anti-virus,
rewall disabled…)"
