Acteon XMIND TRIUM - Page 43

43
ENGLISH
Operator’s manual • X-Mind trium • V0G • (13) • 10/2017 • NTR0EN040G
72 C
"PCDRV_COMM_WDOG_ERR
PC communication timeout"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check all ethernet connections between trium image detectors
and workstation;
check trium ethernet switch;
check that workstation conguration is in accordance with
requirements (network interface card, installed anti-virus,
rewall disabled…)"
73 B
"X_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
X-axis reset"
A
Reset error from workstation; if error remains restart trium and
workstation.
74 C
"X_AXIS_ERR_RES_TOUT
X-axis reset timeout (Uarm movement
parallel to the wall)"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check motor and its cable;
check optoswitch and its cable;
check/replace main board."
75 B
"Y_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
Y-axis reset"
A
Reset error from workstation; if error remains restart trium and
workstation.
76 C
"Y_AXIS_ERR_RES_TOUT
Y-axis reset timeout (Uarm movement
perpendicular to the wall)"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check motor and its cable;
check optoswitch and its cable;
check/replace main board."
77 B
"R_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
R-axis reset"
A
Reset error from workstation; if error remains restart trium and
workstation.
78 C
"R_AXIS_ERR_RES_TOUT
R-axis reset timeout (Uarm rotation)"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check motor and its cable;
check optoswitch and its cable;
check/replace main board."
79 B
"C_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
B-axis reset"
A
Reset error from workstation; if error remains restart trium and
workstation.
80 C
"C_AXIS_ERR_RES_TOUT
C-axis reset timeout (CEPH image
detector slider)"
U/T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check motor and its cable;
check optoswitch and its cable;
check/replace main board."
81 B
"S_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
S-axis reset"
A
Reset error from workstation; if error remains restart trium and
workstation.
