Acteon XMIND TRIUM - Page 33

33
ENGLISH
Operator’s manual • X-Mind trium • V0G • (13) • 10/2017 • NTR0EN040G
The intersection between the mid-sagittal plane laser and the coronal plane laser represents the Axis of Rotation (AOR) of the
scanning apparatus, that is the central axis of the acquired volume.
Once the patient is positioned correctly with respect to the lasers, adjust the chin rest support by means of the control panel
commands in order to reach the correct position.
