10
ePTZ views. Users can implement virtual PTZ by rotating the mouse
wheel (for zoom in / out), and drag the mouse into any direction in the
ePTZ live video panes.
The available Fisheye Image Adjustment buttons are different according to the
dewarping type and installation method selected on the <Fisheye Setting> page.
The following table shows the available buttons in different dewarping types and
installation methods. The supported buttons are represented by “v”.
Dewarping Type/
Installation Method
Button
Front End Correction
Back End Correction
Ceiling
Mount
Wall
Mount
Ceiling
Mount
Wall
Mount
Overview
v
v
v
v
Single ePTZ
v
v
v
v
360° Panoramic
V
-
v
-
4PTZ (Quad View )
v
-
v
-
180° Panoramic
-
V
-
v
180° Dual ePTZ
-
v
-
v
NOTE: If the Fisheye Dewarping Type is selected as <Front End>,
please go to <Streaming> tab→<Configuration> page to set [Source]
and [Resolution] items for stream(s). Refer to the section Fisheye
Setting (Fisheye IP Camera Only) under Camera for further details.
