2.4.8 Digital Zoom
The Digital Zoom setting can be found under this path: Camera> Digital Zoom.
The digital zoom of the camera is adjustable from x2 to x10.
NOTE: This function is NOT available for Fisheye IP Camera models.
2.4.9 Backlight (for select models only)
The Backlight setting can be found under this path: Camera> Backlight.
Backlight function is NOT available when TV system is set as “WDR 2 Shutter”.
The Backlight Compensation function prevents the center object from being too
dark in surroundings where excessive light is behind the center object. Select
<on> to turn on the function; otherwise, select <off> to turn off the function.
2.4.10 Fisheye Setting (Fisheye IP Camera Only)
The Fisheye setting can be found under this path: Camera> Fisheye Setting.
At this setting page, users can choose a dewarping type for correcting the
fisheye source images, and select the camera’s installation method to view the
dewarped images with the correct viewing modes. Please refer to the following
sub-sections Fisheye Dewarping Type and Installation for more details.
After a suitable dewarping type and the correct installation method are selected,
users can view the dewarped images from the camera’s web browser
configuration interface. Click on the Fisheye Image Adjustment buttons on the
home page and view the dewarped images in the preferred viewing mode.
Alternatively, users can view the dewarped images through a backend device or
via backend software that has dewarping function. Please refer to its User’s
Manual for more details.
NOTE: The Fisheye Image Adjustment buttons are different according to
the dewarping type and installation method selected at this setting page.
Please refer to the tables at sub-section Fisheye Image Adjustment
under section Function Items on Home Page for the supported buttons.
