frequency as the upload frame rate. The setting range is from 1 to 15
frames per second.
NOTE: Make sure SMTP configuration has been completed.
Refer to section Mail for further details.
Send HTTP Notification
Check this item, select the destination HTTP address, and specify the
parameters for event notifications by <Motion Detection> triggered.
When an alarm is triggered, the notification can be sent to the specified
HTTP server.
For instance, if the custom parameter is set as “action=1&group=2”, and
the HTTP server name is “http://192.168.0.100/admin.php”, the
notification will be sent to HTTP server as “http://192.168.0.100/
admin.php/action=1&group=2” when alarm is triggered.
Record Video Clip
Check this item and select a video recording storage type, <SD Card> or
<NAS> (Network-Attached Storage>. The Motion Detection recording
will be stored in microSD/SD card or the NAS when motion is detected.
Pre-trigger buffer recording function allows users to check what caused
the trigger. The pre-trigger buffer time range is from 1 sec. to 3 sec.
Select <Upload for __ sec> to set the recording duration after motion is
triggered. The setting range is from 1 to 99999 sec. Select <Upload
during the trigger active> to record the triggered video until the trigger is
off.
NOTE: Please make sure the local recording (with microSD/SD
card) or the remote recording (with NAS) is activated so that this
function can be implemented. Refer to section Recording for
further details.
