Select <Upload for __sec> and enter the duration in the blank.
The images of the duration will be uploading by E-mail when the alarm
input is triggered. The setting range is from 1 to 99999 sec. Select
<Upload during the trigger active> to make the images keep being
uploaded to E-mail during the trigger active until the alarm is released.
Set the Image frequency as the upload frame rate. The setting range is
from 1 to 15 frames per second.
NOTE: Make sure SMTP configuration has been completed.
Please refer to section Mail for further details.
Send HTTP notification
Check this item, select the destination HTTP address, and specify the
parameters for
event notifications
by <Alarm>
triggered. W
hen an a
larm
is triggered, the notification can be sent to the specified HTTP server.
For instance, if the custom parameter is set as “action=1&group=2”, and
the HTTP server name is “http://192.168.0.1/admin.php”, the notification
will be sent to HTTP server as “http://192.168.0.1/admin.php?
action=1&group=2” when alarm is triggered.
Record Video Clip
Check the item and select a video recording storage type, <SD Card> or
<NAS> (Network-Attached Storage). The alarm-triggered recording will
be saved into the microSD/SD card or the NAS.
Pre-trigger buffer recording function allows users to check what caused
the trigger. The pre-trigger buffer time range is from 1 to 3 sec. Select
<Upload for __ sec> to set the recording duration after alarm is triggered.
The setting range is from 1 to 99999 sec. Select <Upload during the
trigger active> to record the triggered video until the trigger is off.
NOTE: Please make sure the local recording (with microSD/SD
card) or the remote recording (with NAS) is activated so that this
function can be implemented. Refer to section Recording for
further details.
