ACTi B412 - Pan and Tilt the Camera

www.acti.com
Hardware Manual
17
5. Attach the camera to the surface using the three (3) supplied screws.
Step 4: Pan and Tilt the Camera
1. Slightly loosen the Pan Adjustment Knob and pan the camera.
Pan Adjustment Screw
Tilt Adjustment Screw
Pan Adjustment Knob
