How to Waterproof the Cable Using the Conduit Gland
1. Prepare the following items:
Conduit Gland
Gland Rubber Ring
1/2” Flexible Conduit
NOTE: Not included in the
camera package.
2. Detach the conduit gland as shown below.
3. Insert the Ethernet cable through the flexible conduit. Then insert the clamping nut through
the flexible conduit.
Gland Body
Clamping Nut
Sealing Rubber
