ACTi B412 - How to Waterproof the Ethernet Cable Using the Cable Gland

www.acti.com
Hardware Manual
20
How to Waterproof the Ethernet Cable Using the Cable Gland
1. Prepare the following items:
Cable Gland
Gland Rubber Ring
Exterior-Grade
Ethernet Cable
NOTE: Not included in the
camera package.
2. Detach the cable gland as shown below.
3. Insert the clamping nut through the Ethernet cable.
Gland Body
Clamping Nut
Sealing Rubber and Claw
