ACTi D7 Series - Page 11

www.acti.com
Installation Guide
11
3. Screw the gland body to the mount kit.
4. Pull enough length of the network cable and other cables (if any) and insert through the
mount kit to connect to the camera later.
5. Insert the sealing insert into the gland body and then attach the clamping nut to complete the
cable solution.
Using Flex Conduit
