ACTi D7 Series - Waterproof Solution with Naked Cable

www.acti.com
Installation Guide
6
Waterproof Solution with Naked Cable
This section describes the procedures in using the bundled cable gland and an exterior-grade
Ethernet cable.
1. Disassemble the cable gland as shown below:
2. Skip to Step 3: Install the Straight Tube on page 9.
Body
(with Washer)
Sealing Insert
with Claw
Clamping
Nut
