Step 8: Access the Camera Live View
See Accessing the Camera Live View on page 18 for more information.
Step 9: Adjust the Viewing Angle and Focus
Based on the Live View, adjust the viewing angle and orientation of the camera. Adjustments vary
per model, for detailed information, please refer to the following sections:
 For D7x / E7x camera models, see D7x / E7x Series on page 26.
 For D8x / E8x / ACM-7411 camera models, see D8x / E8x Series on page 28.
 For KCM-7111 camera models, see KCM-7111 on page 29.
 For KCM-7311 camera models, see KCM-7311 on page 30.
Step 10: Close the Dome Cover
1. Align the position of the dome cover shroud to the direction of the lens.
2. Tighten the three (3) screws to attach the dome cover to the camera body.
