Storage Manager on ROM
Icon Reference
SMOR uses the following icons in the Tree View:
Screen Layout
The SMOR interface works like the Windows Explorer tree-
structured interface. The screen, shown in Figure 2-1, is divided into
three major components: a menu bar across the top of the screen and
two display panes below the menu bar.
Figure 2-1. Screen Layout
Controller Hard drive CD Array Tape
Other Device
HPT370 HPT370
·
Menu Bar
Tree View
Information & Configuration Tab P
ages
To Next Page
