ADI COMMANDO 246 BM - Autodialer Memory and Sending; Keypad Frequency Entry

37
5-13 DTMF REDIALER OPERATION
The DTMF Redialer Operation is available when the optional DTMF unit
(DTF147) is installed and the DTMF Autodialer operation is disabled
(the telephone icon disappears on display).
The DTMF sequence sent last time in transmission will be sent again by
activating the DTMF Redialer operation.
1.Turn the transceiver to leave DTMF Autodialer operation (the
telephone icon will disappear on display).
2. Press the PTT key, the transceiver goes to transmission mode.
3. In transmission mode, press the VFO key on microphone, the DTMF
sequence sent during last transmission will be sent again.
5-14 KEYPAD DIRECT FREQUENCY ENTRY
The operating frequency could be selected by entering numbers directly
from DTMF microphone when the optional DTMF unit DTF147 is
installed.
1. Press VFO key to enter VFO mode.
2. Press MHz key to start 1 MHz step frequency tuning.
3. Use the microphone keypad to enter the desired frequency.
Enter the digits in order from the most significant digit down to the least
significant one.
4. If the number entered is other than 0 ~ 9, the bu-sound is generated,
and the number is inhibited to be entered. The out-of -band entered
frequency is also inhibited.
5. The entered frequency will be automatically modified for the least
significant digits to match the current frequency step.
5-14 APO (Automatic Power Off)
The automatic power-off function turns the power off automatically if you
forget to turn off your radio.
The initial setting is OFF.
5-15 DIM(Dimmer)
The intensity of illumination can be set to be one of four levels.
1. Press the F key, then press the LOW/DIM key while the F indicator
lights.
1. To turn the APO function off and on, press the F key for longer than 1
second, then MHz/LOCK key within 10 seconds. The APO indicator
lights.
2. If, after the 30 minutes in inactive receive mode, no key has been
pressed, the APO indicator flashes and a beep sounds. After that, all
the functions are disabled, and the transceiver enters the automatic
power-off state.
3. To leave the automatic power-off state, turn the power switch off and
on again.
Note
A small current flows during the automatically power off state. If
the transceiver is not going to be used, be sure to switch the
power off.
