4-2 CONNECTOR
4-2-1 Mobile Installations
Cautions:
1. Before installing the power cable, be sure to remove the
negative lead from the battery for safety.
2. After installation and wiring, be sure to double check for
correct installation before reconnecting the negative lead
to thebattery terminal.
3. If the fuse opens, be sure to check the each conductor has
been damaged by short circuiting, etc. Then replace with a
new fuse of the same rating.
4. After completing the wiring , wrap the fuse holder with heat
resistant tape to protect against heat and moisture.
5. Do not remove the fuse even if the power cable is too long.
A. Battery Connections
Connect the power cable directly to the battery terminals. Using of
the cigarette lighter socket will lead to a poor connection, and will
result in poor performance. Pay close attention to the polarity of the
cables when connecting them to the battery.
B. Ignition Noise
This transceiver has been designed to suppress ignition noise;
however, if excessive noise is present, it may be necessary to use
suppressor spark plugs (with resistors).
