ADOS S.R.L. Buccinasco (MI)
492-MTU10006 Rev. 4 Page 28 of 49
4.3.1 Wiring the instrument to the protective earthing system
Protective conductor terminal must be connected to the protective earthing system by means of
flexible wire having a minimum section of 2,5mmq.
4.3.2 Power supply connection
Connect the power supply to terminals “ 2 ” and “ 3 ” of terminal block M1.
Terminal “ 3 ” must be connected to the earth.
TERMINAL BOARD PIN FUNCTION
M1 1 Earth
M1 2 230 Vac line (0 Vdc with dc version)
M1 3 230 Vac line (+ Vdc with dc version)
UNLESS OTHERWISE INDICATED, THE INSTRUMENT IS SUPPLIED FOR USE WITH
230 Vac POWER SUPPLY
