ADOS S.R.L. Buccinasco (MI)
492-MTU10006 Rev. 4 Page 38 of 49
6.3.3 Graduation
G R A D
It is possible to set the following values:
? 1000
? 2000
? 3000
? 4000
? 5000 (default configuration)
6.3.4 Resolution
R E S O L U
It is possible to set the following values:
? 1 (default configuration)
? 2
? 5
? 10
? 20
? 50
The system does not accept a resolution setting of 50 with 4000 and 5000 graduation (it would not be
possible to present the data on the display).
6.3.5 Decimal point
D E C P N T
It is possible to set the following values:
? 0 (default configuration)
? 0.0
? 0.00
? 0.000
? 0.0000
6.3.6 Averages
A V E R A G
It is possible to set the following values:
? 4
? 8 (default configuration)
? 16
