Ados A100E - Primary Serial Port; Auxiliary Serial Port; Transmission Delay; Receiver Time out

ADOS S.R.L. Buccinasco (MI)
492-MTU10006 Rev. 4 Page 41 of 49
6.3.10 Primary serial port
S E R P
It is possible to set the following values:
? OFF Off (default configuration)
? BIDIR Bi-directional
? CONT Continuous transmission
? DE Print on demand
? MODBUS
6.3.11 Auxiliary serial port
A u x . S e r
It is possible to set the following values:
? CONT Continuous transmission (default configuration)
? DE Print on demand
6.3.12 Transmission delay
D L Y S N D
Values from 0 (default value) to 200 mS can be defined.
6.3.13 Receiver Time out
D L Y R C V
Values from 0 (default value) to 200 mS can be defined.
6.3.14 Address on RS485
4 8 5 A d d r
? It is possible to set values ranging from 0 (default configuration) to 32
6.3.15 Baud rate
B a u d R a t e
It is possible to set the following values:
? 9600 (default configuration)
? 4800
? 2400
