6.3.16 Relay function
R 1 M o d e
R 2 M o d e
It is possible to set the following values:
? OFF Off (default configuration)
? C L Closing on Gross
? C NL Closing on Net upon Loading
? C NU Closing on Net upon Unloading
? O L Opening on Gross
? O NL Opening on Net upon Loading
? O NU Opening on Net upon Unloading
6.3.17 Relay threshold
S E T R 1
S E T R 2
It is possible to set a value ranging from 0 (default configuration) to the full scale (given by the product of
graduation by resolution).
6.3.18 Dead Band
D E A D B 1
D E A D B 2
It is possible to set a value ranging from 0 (default configuration) to the 2% of full scale (given by the
product of graduation by resolution).
