2. OPERATING SPECIFICATIONS
2.1 Technical data
Power supply 230 Vac 50/60 Hz -15%...+10%
120 Vac 50/60 Hz (optional) -15%...+10%
Consumption 10VA (15 VA MAX.)
Fuse 230 Vac: 80 mA Time lag T
120 Vac: 160 mA Time lag T
+ 12 Vdc: 500 mA Fast
+ 24 Vdc 630 mA Fast
Operating temperature from - 10 ?C to + 40 ?C
Storage temperature from - 40 ?C to + 70 ?C
Relative humidity 95% non-condensing
Load cell power supply 8 Vdc (short-circuit proof)
Maximum current 90 mA (4 x 350 ? load cells in parallel)
Electric connection 4 wires
Analog signal 0.5 - 2.5mV/V
Resolution 0.8 ?V/Grad
Conversion speed 55 conversion/sec
Graduation 1000-2000-3000-4000-5000
Resolution 1-2-5-10-20-50
Off scale limit (UL/OL) 20% of full scale load
Display five (5) digits LED
Polarity sign -
Keyboard six (6) keys
Status indicators four (4) LED indicators
Decimal point user defined: 0 - 0.0 - 0.00 - 0.000 - 0.0000
Zero tracking user defined (0.5 - 1 - 2 - 5 - 10 div/s)
AZM aperture user defined (OFF - 1.9% - 100% of F.S.)
Motion band user defined (OFF - 0.5 - 1 - 2 - 5- 10- 20 div)
Serial outputs main output RS232 or RS485 Half-duplex, aux
output RS232, Tx only
Digital outputs two (2) base relay outputs and eight (8) extra
Contact rating 0.5 A @ 24 Vdc
Housing self extinguishing NORYL UL 94 V- (Black) for
front panel mounting according toDIN 43700
Dimensions 72 x 144 x 129 mm
Drilling 68 x 138 mm
Weight 0.7 Kg
Mounting Front panel mounting with two holding brackets
mounted on the sides of the enclosure
