Adrona Crystal EX Trace - Installation of the modules

INSTALLATION
14
Installation of the modules
[1]
Locate the installation slots:
- deionization module (part no. 10310)
- polishing module (part no. 10030)
Installation process of the deionization
module and the polishing module is
identical
[2]
Locate the modules:
1 – deionization module (part no. 10310) is
marked with BLUE sticker;
2 – polishing module (part no. 10030) is marked
with SILVER sticker
[3]
Remove both protective ¼” JG plugs from
DI module.
Option 1.
You need to push the little ring down and you will
be able to take out the plug (see the principle in
chapter ”Introduction to John Guest tubing
system”)
[4]
You can use Adrotool for more convenient removal.
See Adrotool close view picture on the left
