INSTALLATION
13
[6]
Place the module in the slit
[7]
Place connector tubes in slots.
Make sure that connectors are properly attached
[8]
[9]
When the modules and prefilters are installed, it should to look like in pictures no. 8 and no. 9.
Make sure if all the connectors are properly attached and close the front panel
.
