ADS-tec OPC8008 - Order of Installation (OPC8008)

OPC8000 series 29
© ADS-TEC GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen
4.11 Order of installation (OPC8008)
ACHTUNG
The screws have to be tighten with a torque
of 0.25 NM
1) Before the device can be integrated in the panel, the tensioner fixing screws must be
loosened until the tensioners open.
(Item 1 - item 2).
Information:
Tensioners can be opened by using an Allen key of 3 mm size.
