12.3 Replacing the lithium battery (OPC8000 series)
Loosening / removing the retaining bracket
This battery is secured by a plugged-in retaining bracket. The retaining bracket can be
removed from the battery holder by carefully lifting the external tabs with a flat tool
(screwdriver).
Installing / replacing the battery
The lithium battery can now be removed. It may only be replaced with a battery of the same
type. The type of battery to be used is:
Lithium battery 1/2AA 3V (e.g., ADS-TEC part number: DZ-SONS-04100-0)
Ensure the correct polarity when inserting the battery
There is a risk of explosion if the battery is
replaced with the wrong type or with the
wrong polarity. Observe the regulations for
environmentally sound disposal of used
batteries.
