ADS-tec OPC8008 - 12 Component Replacement; Opening the Service Slot (OPC8008)

OPC8000 series 52
© ADS-TEC GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen
12 Component replacement
ATTENTION
Make certain that all cables are disconnected
and that no voltage is connected to the
device!
12.1 Opening the service slot (OPC8008)
Remove the four screws for the service slot on the rear of the device.
Fig.
13
:
