ADS-tec OPC8008 - Replacing the Fan (OPC8013-8022)

OPC8000 series 58
© ADS-TEC GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen
12.5 Replacing the fan (OPC8013-8022)
ATTENTION
Before the device fan can be replaced, the
fan cable must be unplugged!
Removal
Use a size Tx 10 screwdriver to remove the fan screws. The fan can then be lifted out and
replaced with a new one.
Installation
Screw the previously removed screws back in and plug the fan cable in again.
