ADS-tec OPC8008 - Opening the Service Slot (OPC8013-8022)

OPC8000 series 54
© ADS-TEC GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen
12.2 Opening the service slot (OPC8013-8022)
Remove the four screws for the service slot on the rear of the device. The screws can be
removed with a size Tx 10 screwdriver. The rear cover can be tilted forward and removed
using the groove on the top side of the service slot.
Fig.
15
:
