ADS-tec OPC8008 - Page 50

OPC8000 series 50
© ADS-TEC GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen
Power
adapter
24 V DC +/– 20% (19 to 29 V)
Operating system
Windows Embedded
Standard 7 (32 Bit)
Windows 7 Ultimate
(32 Bit)
Windows Embedded Standard 7 (32 Bit / 64 Bit)
Windows 7 Ultimate [for Embedded Systems] (32 Bit / 64 Bit)
Windows Embedded 8.1 Industry Pro (32 Bit / 64 Bit)
Protection class
Front-side IP65
Optional casing IP65
Operating temperature
0°C to +55°C*
–20°C to +55°C*
5°C to +45°C
–20°C to +60°C*
5°C to +45°C
Dimensions (W x H x D)
258 x 194 x 62 mm
353 x 261 x 63 mm
426 x 303 x 66 mm
567 x 369 x 66 mm
Installation depth
50 mm
51 mm
54 mm
54 mm
Installation recess ***
240 x 176 mm
332 x 240 mm
392 x 269 mm
532 x 334 mm
Weight
Approx. 1.8 kg
Approx. 3.6 kg
Approx. 4.9 kg
Approx. 8.6 kg
Vibration
DIN EN 60068-2-6
Shock resistance
DIN EN 60068-2-27
Humidity
10 to 85% non-condensing
Pos: 40 /Datentec hnik/Service und Support/Ser vice & Support @ 2\mod_12 54312498746_6.d oc @ 6472 @
* Only for versions with mSATA-Form factor SSD with extended temperature range
** Shared memory
*** Tolerance + / - 1 mm
**** only with processors of the 4th generation (i5-2002E, Celeron 4400E)
