6270ADT Installation and Setup Guide
3–2
LED DESCRIPTION
ARMED ON – Security system is armed.
OFF – Security system is not armed.
READY ON – Security system is disarmed and ready to arm.
OFF – Security system is armed or disarmed but not ready. If
disarmed, faults or troubles are present.
MESSAGE FLASHING – The 6270ADT contains message(s) for the User
OFF – No messages.
Front Panel Buttons
BUTTON DESCRIPTION
HOME Used to return to the HOME screen display from any sub-
menus.
FUNC Reserved for future use.
PANIC Used to display the EMERGENCY screen (Fire or Panic signal
generation).
BACK Used to exit the current screen display and return to the prior
screen display.
▲
Used to scroll through screen lists in an upward direction.
▼
Used to scroll through screen lists in a downward direction.
